Dimensions - +Gf+ 2298 Bedienungsanleitung

Instruction manual
3.4.2 Linearity error
15 mm
10 mm
5mm
2 mm
0 mm
0.5 mm
-2 mm
-5 mm
-10 mm
-15 mm
A B
3.5

Dimensions

Encapsulated antenna
⌀1"
29 0.78
⌀1½"
Type 2298 80 GHz Radar Level Sensor
Pos. Designation
- - - -
Transmitters up to 10 m measuring range
_ _ _ _ Transmitters up to 20 m measuring range
A Process connection plane of the device
B The minimum measurement distance below
which the radar cannot measure, due to the
insertion length of the antenna (X
C Maximum measurement distance (X
C
)
m
)
M
15
