10.2 Maintenance work on the pressure vessel/
condensed water (Fig. 1)
m IMPORTANT!
To ensure a long service life of the pressure ves-
sel (6), drain off the condensed water by opening
the drain valve (8) each time after using.
Release the vessel pressure first (see 10.4.1).
Open the drain screw by turning counter-clockwise
(looking at the screw from the bottom of the com-
pressor) so that all the condensed water can run out
of the pressure vessel. Then close the drain screw
again (turn it clockwise). Check the pressure vessel
for signs of rust and damage each time before using.
Do not use the compressor with a damaged or rusty
pressure vessel. If you discover any damage, then
please contact the customer service workshop.
10.3 Safety valve (Fig. 2/Pos. 12)
The safety valve (12) has been set for the highest
permitted pressure of the pressure vessel. It is not
permitted to adjust the safety valve or remove the
connection lock (12.2) between the exhaust nut (12.1)
and its cap (12.3).
Actuate the safety valve every 30 operating hours but
at least 3 times a year, to ensure that it works when
required. Turn the perforated exhaust nut (12.1) coun-
terclockwise to open it and use your hands to pull the
valve rod outwards over the perforated exhaust nut
(12.1) to open the safety valve outlet. Now, the valve
audibly releases air. Then, tighten the exhaust nut
clockwise again.
10.4 Storage
m Important!
Pull out the mains plug and ventilate the equip-
ment and all connected pneumatic tools. Switch
off the compressor and make sure that it is se-
cured in such a way that it cannot be started up
again by any unauthorized person.
m Important!
Store the compressor only in a dry location
which is not accessible to unauthorized persons.
Always store upright, never tilted!
10.4.1 Releasing excess pressure
Release the excess pressure by switching off the
compressor and using the compressed air which is
still left in the pressure vessel, e.g. with a compressed
air tool running in idle mode or with a blow-out pistol.
22 | GB
10.5 Spare-part ordering
Please quote the following in your order for spare
parts:
• Type of device
• Article No. of device
• Ident. No. of device
• Spare Part No. of the required spare part
10.6 Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Cylinder, piston, piston rings
* Not necessarily included in the scope of delivery!
11. Disposal and recycling
The equipment is supplied in packaging to
prevent it from being damaged in transit. The
raw materials in this packaging can be re-
used or recycled. The equipment and its ac-
cessories are made of various types of mate-
rial, such as metal and plastic. Defective
components must be disposed of as special waste.
Ask your dealer or your local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must
not be disposed of together with domestic
waste in compliance with the Directive
(2012/19/EU) pertaining to waste electrical
and electronic equipment (WEEE). This product must
be disposed of at a designated collection point. This
can occur, for example, by handing it in at an author-
ised collecting point for the recycling of waste electri-
cal and electronic equipment. Improper handling of
waste equipment may have negative consequences
for the environment and human health due to poten-
tially hazardous substances that are often contained
in electrical and electronic equipment. By properly
disposing of this product, you are also contributing to
the effective use of natural resources. You can obtain
information on collection points for waste equipment
from your municipal administration, public waste dis-
posal authority, an authorised body for the disposal of
waste electrical and electronic equipment or your
waste disposal company.
