1 Introduction
Goldanalytix, a trademark of MARAWE GmbH & Co. KG and founded in 2012, is one of the
leading providers of precious metal testing methods in Germany. With the GoldScreenPen, we
offer a testing device for measuring the electrical conductivity using inductive eddy current
measurement. The measuring device enables the reliable testing of coins and small bars made of
gold, silver and other precious metals. The measuring tip is equipped with one of the world's
smallest sensor coils, allowing the conductivity value to be measured precisely even with small
contact surfaces, making it possible to measure for example 1/10 ounce coins or 1 g bars. The
penetration depth varies depending on the conductivity of the measured material and ranges up
to 0.7 mm. In this way, even larger objects, such as 10 g bars or 1 ounce coins, can be verified for
authenticity. In general, the testing device is suitable for measuring most metals and alloys and is
therefore ideal for use in the recycling sector. With certain restrictions, the GoldScreenPen can
also be an excellent tool for testing jewellery (see Chapter 6: Evaluation and Interpretation of
the Results).
By the way: On our homepage at www.gold-analytix.com you will always find the latest version
of the instruction manual, so that you can keep up to date with new types of forgery and findings
around precious metal testing.
2 Safety Instructions
IMPORTANT: Please read this instruction manual carefully before using the GoldScreenPen for
the first time. This is for your own safety and to ensure proper operation of the device. Keep the
instruction manual in a safe and easily accessible place and, if necessary, pass it on to
subsequent users. When using the GoldScreenPen, please follow the safety instructions.
Definition of signal words and warning symbols:
Safety instructions are marked with signal words and warning symbols. Disregarding the safety
instructions can lead to personal danger, damage, and malfunction of the device, as well as
incorrect results.
Signal words:
CAUTION!
moderate injury and damage to the device or property.
20
B English
Indicates a low-risk hazard which, if not avoided, could result in minor or
