For the daily cleaning of both taps you must remove the upper part as shown in the images
(Fig. 13.2 y 14.2+). The Up tap is dismantled by turning the plastic ring on the tap body and
then removing the button. The S +plus tap is dismantled by turning the ring on the metal
body.
Detector tube gasket (46)
If required, this gasket can be removed for cleaning (Fig. 3U or 4).
Machine supplement (47)
Use this supplement to raise the machine (Fig. 3U or 3+).
Important! Never place the machine onto the supplement alone, it should always be done by at
!
least two people.
Tank Juice Container (50)
Line up the two side lugs at the ends of the container and press. Pressing the side buttons may help
mount it (Fig. 15).
To remove the container, just press the side buttons and pull out towards you.
Tank Sub-filter (51)
Place on the inside of the juice extraction container (Fig. 5+).
