Assembly and detachment of
components according to model
Right cover side outlet (2), Left cover side outlet (3), Left cover side outlet S
The side outlets are not the same. Ensure that the correct side outlet is installed on the corresponding
side.
Assembly of the outlets (Fig. 10).
Line up the bottom of the side outlet and lift up the upper part, ensuring that it closes with
a 90º turn of the knob.
Mount the right outlet by turning the latch clockwise.
Mount the left outlet by turning the latch counter-clockwise.
!
Important! There are icons on the part indicating the direction of the turn, do not force the tab
in the opposite direction.
Ensure that the side outlets are fully installed and correctly positioned in their place.
Disassembly of the outlets (Fig. 10)
Remove the right outlet by turning the latch counter-clockwise to its vertical position.
Remove the left outlet by turning the latch clockwise to its vertical position.
Cover (1)
Assembly of the cover (Fig. 10.1)
Check that the knobs on the shafts of the machine are turned perpendicular to the floor (open)
Hold the cover by the outlet holes, match the holes with the knobs and press until they are
completely inserted. Turn the knobs 90º degrees clockwise to secure the cover.
Important! Avoid forcing the cover onto the machine if the shafts are not completely aligned,
!
as this may damage the part.
Disassembly of the cover (Fig. 10.1)
Turn the knobs 90º degrees until they align with the holes in the cover.
Remove the cover with a horizontal movement, holding it with both hands by the outlet holes.
Important! Avoid forcefully removing the cover if the shafts are not completely aligned, as this
!
may damage the part.
