SIW 6TES - SIW 11TES
5

Transport

5.1 General

A lift truck is suited for transporting the unit on a level surface.
Carrying straps may be used if the heat pump needs to be trans-
ported on an uneven surface or carried up or down stairs. These
straps can be passed directly underneath the pallet.
ATTENTION!
In installed and dismantled state, the heat pump module may only be
tilted by a maximum of 45° (in each direction) ( see Cap. 5.3 on pag. 7).

5.2 Removing the casing panels

All panelling can be removed to allow accessing the inside of the
device.
Fig. 5.1: open front plate bottom
EN-6
Fig. 5.2: open front plate top
Fig. 5.3: open side plates
