Specifications; Cutting Blade; Stihl Ap Battery - Stihl Rma 2.2 Rv Gebrauchsanleitung

21 Specifications

Error LEDs on the
battery
The STIHL con‐
nected app is
unable to find the
battery with .
20.2 Product Support and Assis‐
tance on Use
Product support and assistance on use are avail‐
able from STIHL servicing dealers.
For contacts and other information, please visit
https://support.stihl.com or www.stihl.com.
21 Specifications
21.1 Activating and Deactivating the
Blade
21.1.1 Activating the Blade
► Place the lawn mower on a level surface.
► Press locking button (1) with the right hand
and hold.
► Pull control bar for mowing (2) with the left
hand fully in the direction of handlebar (3) and
hold so the thumb encloses handlebar (3).
The blade turns.
► Release locking button (1).
► Hold handlebar (3) and control bar for mow‐
ing (2) with the right hand so the thumb enclo‐
ses handlebar (3).
21.1.2 Deactivating the Blade
► Release the control bar for mowing.
► Wait until the blade is no longer turning.
► If the blade continues to turn: remove the bat‐
teries and consult a STIHL specialist dealer.
The lawn mower is defective.
0478-131-9950-D
Cause
®
The Bluetooth radio
interface on the bat‐
tery or mobile device
is deactivated.
Excessive distance
between the battery
and the mobile
device.
21.2
– Approved battery: STIHL AP
– Weight without battery:
– RMA 2.2 RV: 22,4 kg
– RMA 2.2 RPV: 22,6 kg
– Weight (m) with 2 batteries of type
STIHL AP 500 S:
– RMA 2.2 RV: 27 kg
– RMA 2.2 RPV: 27 kg
– Cutting width: 46 cm
– Motor speed (n): 3150/min
– Motor speed in ECO mode: 2800/min
– Degree of electrical protection: IPX4
– Minimum travel speed: 2,0 km/h
– Maximum travel speed (depending on the bat‐
tery used):
– 200: 3,7 km/h
– 300 S: 4,5 km/h
– 500 S: 4,5 km/h
For runtime, see www.stihl.com/battery-life.
21.3
– Minimum thickness a: 2 mm
– Minimum width b: 45 mm
– Sharpening angle c: 30°
21.4
– Battery technology: Lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
Remedy
► Activate the Bluetooth
on the battery or mobile device.
► Reduce the distance,
► If the STIHL connected app is still
unable to find the battery: Contact a
STIHL authorized dealer.
Lawn mower
STIHL RMA 2.2 RV,
RMA 2.2 RPV

Cutting blade

STIHL AP Battery

English
®
radio interface
21.4.
47
