Description Of Functions; Technical Data - Parkside Pstda 20-Li C3 Originalbetriebsanleitung

21 Guard cover
22 LED work light
23 Release (Chuck)
24 Recess in slide shoe
25 Splinter guard
26 Holder (Hex key)
27 Hex key
28 Parallel guide
29 Charger
30 Charge level indicator
31 Button (Charge level indicator)
32 Battery release
33 Storage case

Description of functions

With the jigsaw, the saw blade
clamped on one side cuts via a
stroke movement. With the pendulum
stroke, the guide roller moves the saw
blade forwards during every upstroke
in addition to the vertical saw move-
ment.
Please refer to the descriptions below
for information on how the operating
elements work.

Technical data

Cordless Jigsaw .... PSTDA 20-Li C3
Rated voltage U ...................... 20 V ⎓
Weight with battery (20 V; 2 Ah)
...................................................2.3 kg
Idle stroke rate ............... 0–2700 min⁻¹
Stroke length ........................... 20 mm
Cutting depth
– wood ................................. ≤ 80 mm
– Aluminium ..........................≤ 12 mm
– metal ................................... ≤ 5 mm
Bevel cutting
.............−45°; −22.5°; 0°; 15°; 30°; 45°
Sound pressure level (L
.............................84.51 dB; K
)
pA
=5 dB
pA
Sound power level (L
– Measured ........ 92.51 dB; K
Vibration (a )
h
– wood .......... 2.709 m/s²; K=1.5 m/s²
– metal ...........2.540 m/s²; K=1.5 m/s²
Temperature ............................ ≤50 °C
– Charging ............................. 4–40 °C
– Operation ........................−20–50 °C
– Storage ............................... 0–45 °C
PARKSIDE Performance Smart
battery Smart PAPS 204 A1/
Smart PAPS 208 A1
– frequency band .. 2400–2483.5 MHz
– transmitted power ............≤ 20 dBm
Notes on noise and vibration values
CAUTION! Hearing damage! Wear
ear protection.
The specified total vibration values
and the stated noise emission values
have been measured according to a
standardised test method and can be
used to compare one power tool with
another. The specified total vibration
values and the stated specified noise
emission values can also be used for
a provisional assessment of the load.
WARNING! The vibration and
noise emissions may deviate from the
specified value during actual use of
the power tool, depending on how
the power tool is being used and,
in particular, what kind of material
is being worked on. Safety meas-
ures for protection of the operator are
to be determined that are based on
an estimate of the vibration load un-
der the real operating conditions. All
parts of the operating cycle have to
be considered while doing so – for
example, times when the power tool
is switched off and times when it is
switched on but running without any
load.
GB MT
)
WA
=5 dB
WA
27
