Proper use

This device is only intended for the
following uses:
• Sawing plastic, wood and light
metal with firm support
• Sawing straight and curved cuts as
well as mitre cuts (only wood and
plastic) of up to 45°
• Only operate in dry areas.
Please note the information on saw
blade types.
Any other use that is not expressly
permitted in this instruction manu-
al may pose a serious hazard to the
user and result in damage to the
device. The operator or user of the
machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
The device is part of the
X 20 V TEAM series and can be
operated with batteries of the
X 20 V TEAM series. Batteries of
the X 20 V TEAM series may only
be charged using chargers of the
X 20 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Cordless Jigsaw
• 1 × Wood saw blade (Swiss made,
Clean cut)
• 1 × Wood saw blade (Swiss made,
High sawing progress)
• 1 Metal saw blade (Swiss made)
26
• Parallel guide
• Slide shoe (pre-assembled)
• Splinter guard (pre-assembled)
• Guard cover (pre-assembled)
• Reducer piece (pre-assembled)
• Hex key (stowed on the device)
• Storage case
• Translation of the original instruc-
tions
The rechargeable battery and char-
ger are not included in delivery.

Overview

The illustrations for the
device can be found on
the front and back fold-
out page.
1 Switch lock
2 On/Off switch
3 Handle (Insulated gripping sur-
face)
4 Battery
5 Battery holder
6 Suction nozzle
7 Reducer piece
8 Notch
9 Slide shoe
10 Switch (dust blower function)
11 Hexagon socket screw (not vis-
ible)
12 Footplate
13 Pendulum stroke switch
14 Chuck
15 Guide roller
16 Metal saw blade (Swiss made)
17 Wood saw blade (Swiss made,
Clean cut)
18 Wood saw blade (Swiss made,
High sawing progress)
19 Mount (Parallel guide)
20 Retaining screw
