. Connecting the water drainage pipe
2
Pull out the water drainage cap with black color (indicated A in above
illustration), then connect the white drainage pipe included in accessory,
again connect the other end of this drainage to the main water drainage
pipeline. Make sure not to set the drainage pipe too high.
3. Connect the water hose to the water faucet of the water main supply
system (For automatic water supplying)
First, install the supplied water quick-connector(from 1/4 to 1/2 inch, with
black sealing circle) to the water faucet by screw thread; Second, remove
the clipper from the water quick-connector, insert the another end of the
water hose into this quick-connector port completely, then install back the
clipper, also this step is completed. Note: The water faucet should be
supplied by the customer himself.
Important: The water pressure of main water supply system must be 0.04-
05 MPa at least and 0.6 Mpa at largest. If the pressure is too big (like
bigger than 0.8 Mpa), it should be installed with pressure
decreasing valve first.
Note: If you need the unit set by manual water filling, don't need to do
step 1 and 3.
If you choose the automatic water supplying, the ice maker requires a
continuous water supply with pressure 1-6 Bar as required in above
specification table.
Operation the ice-making process
Selecting the water supplying mode
Plug on the unit , press the button in the little hole of the control panel, you
can change the water supplying mode of your unit.
Water supplying Mode
Setting Switch
TIMER
CLEAN
ON/OFF
Use a thinpole to
press this witch in
this little hole,
to←change the
water supplying
mode between
automatic and
manual.
Default model: Automatic
14
After setting once:Manual
I:Symbol of Manual water suppling
O:Symbol of Automatic water supplying
