Power Focus 4002 Compact
General information
EC DECLARATION OF CONFORMITY
We, Atlas Copco Industrial Technique AB, S-105
23 STOCKHOLM SWEDEN declare under our
sole responsibility that our product (with type and
serial number, see front page) and in combination
with our accessories, to which this declaration re-
lates is in conformity with the appropriate stan-
dard(s):
EN 61010-1, EN 60204-1, EN 61000-3-2:2006,
EN 61000-3-3:2008, EN 61000-6-2:2005, EN
61000-6-3:2007
and in accordance with the following directive(s):
2004/108/EC, 2006/95/EC
Technical file available from:
Quality Manager, Atlas Copco Tools, Stockholm,
Sweden
Conformity to North American
standards
3028592
Signature
Stockholm, 1 July 2012
Tobias Hahn, Managing Director
Signature of issuer
Installation
Installation checklist
This Power Focus is a control and monitoring
unit for electric assembly tools. The ready-to-
run fastening system consists of:
• a Power Focus controller. Two different hard-
ware versions are available, the Graph and the
Compact. The user interface and the dimen-
sions are the main differences between them.
Listed
Conforms to UL
61010-1
Certified to CSA C22.2
No. 61010-1
© Atlas Copco Industrial Technique AB - 9836 4581 00
• an RBU, Rapid Backup Unit, enabling the cor-
responding level of functionality (Bronze, Sil-
ver, Gold, X, DS)
• a tool cable, available in different models and
lengths
• and a tool. The Tensor S/ST/SL tool is avail-
able in different configurations and torque
ranges.
Installation procedure
1. Mount the controller on the wall or steel plate
with four M6 screw. If mounting on a wall,
make sure to use correct wall bracket (plug and
screw). If mounting on a steel plate, make sure
that the thickness of the plate is minimum 2
mm.
2. Open the locking mechanism
Open the controller slowly towards you, not to
3.
cause injury or damage
Connect the tool cable, power cable etc.
4.
5. Connect the RBU
6. Close the controller and lock it
Connect the power cable to a power supply
7.
(115/230 V)
Turn the power on
8.
Handling
Program a Pset - Compact
Press the AUTOSET key and ASEt/Ft appears
1.
on the display
2. Choose final torque target by pressing +/- keys
3. Press the ENTER key to activate the Autoset
function
The Autoset symbol LED lights up
4.
Make 5-8 tightening until the LED goes out
5.
Optimum performance has been found and the sys-
tem is ready for production.
Program a Pset - Graph
1. Press the PROG key and select Pset then Quick
Prog with the arrow keys
2. Enter the final torque target with the alpha-nu-
merical keys
Press the ENTER key to activate the Autoset
3.
function
