Check before use!
• Check the safe condition of the device:
• Check the device for leaks.
• Check the device for visual defects.
• Check that all parts of the device have been se-
curely fitted.
• Check that all safety devices are in proper condi-
tion.
Start Fig. 17, 19-23
Once the machine has been set up properly, start the
engine as follow:
1. Turn the engine switch to the ON position. Fig. 20
2. Put the choke lever on the
3. Press the fuel pump more than 5 times. Fig. 19
4. Pull the recoil starter handle (9) 3-5 times to start
the engine. Fig. 21
Never place feet on the shaft or kneel on it.
5. Once the motor is running, briefly wait, then put
the choke lever into position.
6. To start the cutting tools, operate the release le-
ver (8) with the palm of your hand, and the throttle
lever (11) with your fingers. The further you push
the throttle lever, the higher the motor speed.
When releasing the throttle lever, the motor be-
comes idle and the cutting tools stop. Fig. 23.
The cutting tools should not continue turning and
should not move when the motor is idle.
7. If there are problems, immediately turn the motor
switch (7) to "0" so the motor stops. Caution: The
cutting tools may continue turning for a few sec-
onds. Fig. 23
8. If any problem occurs, pull the pin of safety belt,
then release the brush cutter immediately. Fig. 17
9. If the motor is warm, you can leave the choke le-
ver in the "warm start and work" position.
Note: If the engine does not start up even after sev-
eral attempts, read the section „Engine troubleshoot-
ing".
Note: Always pull the starter cord out in a straight
line. If it is pulled out at an angle, then friction will oc-
cur on the eyelet. As a result of this friction, the cable
will become frayed and will wear away faster. Always
hold the starter handle when the cable retracts.
Never allow the cable to snap back when it has been
pulled out.
Note: Do not start the motor in tall grass.
m Attention: When the engine has been switched
off, the cutting unit continues running for several sec-
onds therefore do not touch the cutting unit until it
has come to a standstill!
position. Fig. 20
Fig. 22
www.scheppach.com
9. Working instructions
Working with brush cutter / grass trimmer
• When you work with the petrol brush cutter for the
first time, familiarize yourself with the operation
and control of the petrol cutting blade without run-
ning engine.
• The design of the petrol brush cutter allows for op-
eration only at the right side of the user's body.
• Keep the petrol brush cutter firmly with both hands
on the handles.
• Always make sure that the cutting tool continues to
rotate briefly after the throttle has been released.
• Always so that the cutting tool no longer turns in a
proper engine idle not press down the throttle.
• Always work with high speed so you have the best
cutting results.
• Poke when working on a stone or a tree, turn off
the engine and remove the spark plug then exam-
ine the petrol brush cutter for damage.
• Caution: Always be extra careful when working in
difficult terrain and slopes. Cut tall grass gradually
so as not to overload the unit.
• Always wear safety glasses and hearing protection
and a safety helmet.
• Use the cutting blade to comb through brushwood,
rank growth, young tree populations (trunk diame-
ter of maximum 2 cm), and high grass.
• While using metal cutting tools, there is generally
a risk of recoil, when the tool hits a solid obstacle
(stones, trees, branches, etc.). Thereby, the tool is
hurled backwards against the rotating direction.
• To cut rank growth and brushwood, you "immerse"
the cutting blade from the top.
CAUTION: Be especially careful, when using this
working technique, because the further away the cut-
ting tool is from the ground, the higher is the risk that
objects to be cut and particles will be hurled side-
ways.
Mowing with grass trimmer
• Use the plastic line cassette for a clean cut also at
uneven edges, fencing posts, and trees.
• Carefully advance the trimming line to an obstacle,
and use the tip of the line to cut around the ob-
stacle. When the trimming line comes into contact
with stones, trees, and walls, the line wears out or
breaks off ahead of time.
• Never replace the nylon line with a metal wire.
RISK OF INJURIES
Automatic thread trimming (Fig. 36)
The petrol cutting blade is delivered with a filled line
cassette.
This line will wear out during work. To feed new line,
forcefully press the head of the line cassette onto the
ground while the engine is running at working speed.
GB | 39
