IO-Link Dokumentation
7.3
Objektverzeichnis
7.3.1
Standard-Objekte
7.3.1.1
Objekt 0x0000: Direct Parameter Page 1
Index
Subindex
IO-Link Bezeichnung
0x00
MasterCommand
0x01
MasterCycleTime
0x02
MinCycleTime
0x03
M-sequence Capability
0x04
RevisionID
0x05
ProcessDataIn
0x0000
RecordT
0x06
ProcessDataOut
0x07
VendorID 1 (MSB)
0x08
VendorID 2 (LSB)
0x09
DeviceID 1 (Octet 2, MSB)
0x0A
DeviceID 2 (Octet 1)
0x0B
DeviceID 3 (Octet 0, LSB)
0x0F
SystemCommand
optoNCDT 1220-IO
Typ
Zugriff Wert /
Default Value
W
0x00 to 0x59 Reserved
0x5A Fallback
0x5B to 0x94 Reserved
0x95 MasterIdent
0x96 DeviceIdent
R/W
UINT8
R
0x05 -> 500µs
UINT8
R
0x29 -> 41
UINT8
R/W
0x11 -> Revision 1.1
UINT8
R
0x83 -> 4 Bytes, no SIO
UINT8
R
0x00
R
0x04, 0x26 -> 1062
UINT16
R/W
MB 010 (7A , 5C, 40) -> 8019008
MB 025 (7A , 5C, 41) -> 8019009
MB 050 (7A , 5C, 42) -> 8019010
UINT32
MB 100 (7A , 5C, 43) -> 8019011
MB 200 (7A , 5C, 44) -> 8019012
MB 500 (7A , 5C, 45) -> 8019013
W
siehe SystemCommand 0x0002
0x97 DeviceStartup
0x98 ProcessDataOutputOperate
0x99 DeviceOperate
0x9A DevicePreoperate
0x9B to 0xFF Reserved
