4. The ba ery meter on LCD will move to indicate the ba ery is charging.
Note:
• It is recommended to power OFF your radio while charging. However, if power is turned on while charging, you may not
be able to transmit a message if the ba ery is completely empty. Allow me for the ba ery to charge to 1 bar before
a emp ng to transmit a message.
• For op mal ba ery life, remove the radio from the charger within 6 hours. Do not store the radio while connected to the
charger.
Chapter 3. Installa on of Accessories
Before the radio is ready for use we need to a ach the ba ery pack, as well as charge the ba ery.
3.1 Installing/ Removing the Antenna
1). Installing the Antenna: Screw the antenna into the connector on the top of the transceiver by holding the antenna at its
base and turning it clockwise un l secure.
2). Removing the Antenna: Turn the antenna counter-clockwise to remove it.
3.2 Installing the belt clip
1). At the back of the radio there are two parallel screws mounted above the ba ery, remove these and thread them
through the holes on the belt clip as you screw them back into the radio body.
2). Removing the Belt Clip: Unscrew counter-clockwise to remove the belt clip.
3.3 Installing the b
Before a aching or removing the ba ery make sure your radio is turned o by turning the power/volume knob all the way
counter-clockwise.
1). Make sure the ba ery is aligned in parallel with the radio body with the lower edge of the ba ery about 1-2cm below the
edge of the radio.
2). Once aligned with the guide-rails, slide the ba ery upward un l you hear a click as the ba ery locks in place.
Remove the ba ery pack
ery pack
