5. ASSEMBLY INSTRUCTIONS
Caution Risk of crushing!
Do not touch the product near the articulated oint.
Step 4
Turn the frame and place the rear support frame on the floor.
Remove the four self tapping screws (
( R). Those are preinstalled to the end caps. Attach the end caps to the front support
frame ( ) using four self tapping screws (
Attach the front support frame ( ) to the frame ( ) and secure with four hexagon socket
screws ( ).
reat leverage is applied to the product s oint.
8R
10
10 10
19
9
) from the end caps of the front stabilizer tube
).
8L
10
1
