Coils suitable for individual or battery installation
NOTE
When installing a battery, the following data must be complied with
for the valves:
Dimensions of the valve housing
Valve housing material
Universal current, Nominal voltage 12...400 V, Frequency 0...60 Hz
Type designation Rated
current [A]
AC10 - .. - 5 - PD73 0,68 ... 0,02
AC10 - .. - 5 - PD74 0,25 ... 0,007
AC10 - .. - 5 - PD75 0,19 ... 0,005
AC10 - .. - 5 - PD76 0,114 ... 0,003 1,25
AC10 - .. - 4 - PD77 0,33 ... 0,01
AC10 - .. - 4 - PD78 0,25 ... 0,007
AC10 - .. - 4 - PD79 0,13 ... 0,003
AC10 - .. - 5 - PD80 0,68 ... 0,02
AC10 - .. - 5 - PD81 0,25 ... 0,007
AC10 - .. - 5 - PD82 0,19 ... 0,005
AC10 - .. - 5 - PD83 0,114 ... 0,003 1,25
AC10 - .. - 4 - PD84 0,33 ... 0,01
AC10 - .. - 4 - PD85 0,25 ... 0,007
AC10 - .. - 4 - PD86 0,13 ... 0,003
32 mm x 32 mm x 10 mm
Brass (Ms),
Stainless steel (VA) or
Plastic (PA 6 GV)
Power Max. Tempeat-
limit permissibl- ure class
[W] e ambient
temperatu-
re [°C]
7 -30 ... +40 T4
3 -30 ... +50 T5
2,25 -30 ... +40 T6
-30 ... +60 T6
4 -30 ... +40 T5
3 -30 ... +50 T5
1,5 -30 ... +55 T6
7 -40 ... +40 T5
3 -40 ... +50 T5
2,25 -40 ... +40 T6
-40 ... +60 T6
4 -40 ... +40 T5
3 -40 ... +50 T5
1,5 -40 ... +55 T6
For battery
installation:
min.
distance
form the
wall [mm]
1
1
1
1
5
5
5
1
1
1
1
5
5
5
