Detachable Accessories and Supplementary Equipment
Acoustic tube
Ear dome
Power Adapter Ratings
Model: EDac EM10681V
AC Input: 100-240 Vac, 2.0-1.0 A, 50-60 Hz
DC Output: 19 V, 3.78 A

Operating Information

Assembly Instructions

Installing the batteries:

• Install the batteries in the AIM System by aligning the battery contacts with the contacts
on the AIM system, placing the bottom of the battery in the recess at the back of the AIM
System, and pressing the battery in place until it latches.
Batteries Installed
Connecting to Power:
• Connect the Power Cord to the AC Adapter
• Connect the DC cable from the AC Adapter to the DC jack on the AIM System
• Plug the Power Cord into an electrical outlet.
• Do not impede disconnection of the power cord/AC Adapter.
8
Contacts
