11. Connect Serial Link. Connect a standard DB9 male
connector to the Link 3 RS232 connector on the proces-
sor for system programming or communications with
other equipment. A standard serial cable (not a null
modem) is required for programming the system using a
laptop. If, at a later date, the processor is connected to a
modem, a null modem adapter will be needed between
the processor and the attached modem.
Mounting
Keyhole (4
places)
PROC POWER
LINK 6 POWER
SHORT
12V
Link 6
15 V
Figure 4 - 4 Series Processor
TM
LINK
3
INIT
1 2 3 4 1 2 3 4
LINK 2 LINK 4
To additional
Dimmer Hubs
To HomeWorks
Maestro controls
®
CONFIGURATION
STATUS
1 2 P E
1 2 3 4 1 2 3 4
LINK 5 LINK 6
Wired
®
Dimmer
Hub
Processor
Label
LINK6
Processor
SHORT
Board
3
