Simons Voss Technologies SmartHandle AX Advanced 105/145 Kurzanleitung Seite 8

6. For door thickness X: have the threaded rods and spindle ready
at hand
6. For door thickness X: have the threaded rods and spindle ready at hand
*X
14
*X
15
PH2
*X
16
Door thickness - 5 mm (±2 mm)
*X
17
Door thickness + 58 mm (±2 mm)
8 / 64
PH2
SmartHandle AX Advanced 105/145
Abbildungen/Images
