7. Installing the fitting
39
40
Size
S
M
M
L
L
X
*X
41
M5 X
16 / 64
Door thickness (mm)
38 – 53
51 – 63
62 – 73
71 – 83
82 – 93
91 – 176
SmartHandle AX Advanced 105/145
Screws
M5×35
M5×40
M5×50
M5×60
M5×70
M5 X
Abbildungen/Images
