GB MT
­ 25­ Chip­ejector
­ 26­ Smart­LED
­ 27­ Charge­level­indicator
­ 28­ ECO­display
29 Preselection button
30 Thermal monitor
­ 31­ Charger
­ 32­ Release­button­(battery)
33 Rechargeable battery
34 Button
­ 35­ Charge­level­indicator
­ 36­ Adjusting­knob
­ 37­ Groove

Functional description

The cordless circular hand saw features
a thermal monitor, a spindle lock and a
working light.Please refer to the descrip-
tions below for information on how the
operating elements work.

Technical data

Cordless
circular saw ........ PPHKSA 40-Li A1
Motor­voltage
U ...... 40­V ­(2­x­20­V)­(Direct­voltage)­
Permitted battery type ......................Li-Ion­
No-load­rotation­speed­n
Weight­(without­battery)....... approx.­4­kg
Max.­cutting­depth
at 0°.........................approx.­62.5­mm
at 45°.......................approx.­46.8­mm
at 48°.......................approx.­44.1­mm
Sound­pressure­level­
(L
) ....................... 88.7 dB, K
pA
Sound­power­level­
(L ) ..................... 99.7 dB; K
WA
Vibration­(a )­sawing­in­wood
h
Handle ......... 0.895 m/s
Auxiliary­handle .0.877 m/s
30
........ 6000 rpm
0
= 3 dB
pA
= 3 dB
WA
2 ; K= 1.5 m/s 2
2 ; K= 1.5 m/s 2
Temperature........................... max.­50°C
Charging ............................. 4­-­40­°C
Operation ...........................-20­-­50°C
Storage ................................. 0­-­45°C
For use with smart batteries
(Smart PAPS 204 A1/Smart PAPS 208 A1)
Operating­frequency/
Frequency band .... 2400­-­2483.5 MHz
Max.­transmission­power .......≤­20­dBm
Saw blade .................................. PSB 24 Z
Dimensions . Ø­190­x­Ø­30­mm­x­1,0­mm­ ­
Teeth thickness/
Cutting­part­thickness ...............1.45 mm
Size of borehole ..................... Ø­30­mm
Number of teeth ........................ 24 teeth
No-load­rotation­speed,­n
The­specified­total­vibration­value­and­the­
stated­noise­emission­value­have­been­
measured according to a standardised test
method and can be used to compare one
power tool with another.
The­specified­total­vibration­value­and­the­
stated­specified­noise­emission­value­can­
also­be­used­for­a­provisional­assessment­
of the load.
Warning: The­vibration­and­noise­
emissions­may­deviate­from­the­
specified­values­during­actual­use­of­the­
power tool, depending on how the power
tool is being used and, in particular, what
kind of material is being worked on.
Safety measures for the protection of the
operator are to be determined that are
based­on­an­estimate­of­the­actual­vibra-
tion load under the real operating condi-
tions­(for­this,­all­parts­of­the­operating­
cycle are to be taken into account, for
example,­times­in­which­the­power­tool­
is turned off, and those during which it is
turned­on­but­running­without­a­load).
-1
.. 8040 min
max
