EN
COMMUNICATION TECHNOLOGY
For information on our full range of connected products
and services, including connection instructions, please
scan QR Code below or visit www.egopowerplus.eu/
connect.
STARTING THE MOWER (Fig. A4 – Fig. A5 & Fig. G1 – Fig.
G6)
WARNING: Avoid sudden starts, stops, and turns, as well as
excessive speed, especially when first learning to operate the mower.
The mower can spin rapidly, which may cause you to lose control and
result in serious injury and/or damage.
WARNING: Before starting the mower, check and make sure
the blades are disengaged within 5s when pushing the PTO switch
downward. If the blades fail to stop, do not use the mower and contact
your EGO customer service immediately.
NOTICE: Follow Fig. A4 & Fig. G2 to get the lowest driving speed and
STANDARD driving mode until you are fully capable of operating the
mower in all situations. The driving speed and driving mode will activate
only when the mower wheels are stopped and the steering levers are
open.
The mower will save and present the previous driving mode, driving
speed and calibration of the steering levers when restarting it.
Driving-Mode
◾
CONTROL: Lower acceleration, less sensitive handling, and mild
turning speed to protect the grass and for new users.
◾
STANDARD: Perfect for everyday use.
◾
SPORT: Higher acceleration, accurate handling, and sharp turning
to maximize mowing efficiency and for mowing enthusiasts.
Driving Speed Adjustment (Fig. A4)
Blade Speed Adjustment (Fig. A5)
USB port
NOTICE: The USB port provides charging power of 5 Voltage DC at up a
combined draw of 1.5 Amperes and is powered only when the mower
is startup.
STOPPING THE MOWER (Fig. H1 – Fig. H6)
NOTICE: After more than 60 minutes without operating, the mower will
automatically shut off.
Limp-home mode
When battery charge becomes low, the mower will go into Limp-Home
26
ZERO TURN RIDE-ON MOWER — ZT5200E-L
mode:
◾
The mower automatically stop grass cutting;
◾
The beep indicator will continue to sound;
◾
The mower status indicator will flash red every second, the first
segment of the mower fuel-gauge will flash red and both the low-
power indicator and the battery graphics on the fuel gauge will
flash.
The operator should:
a) Push the PTO switch downward (Fig. H3) to disengage the blades.
The beep indicator will stop sounding when the blade stops;
b) Stop working and go to the battery charging area as soon as
possible. The maximum distance the mower can travel is 1000 m.
When the battery is nearly depleted, the icon of each occupied battery
compartment and low-power indicator will blink every half a second.
The mower will stop working immediately. The operator should
transport the mower to the battery charging area for charging.
Manual pushing
If manual pushing is needed, be sure that the batteries are
disconnected from the mower and the parking-brake pedal is release
from the braking position.
DRIVING THE MOWER (Fig. I1 – Fig. I9)
To stop, decrease or increase speed, slowly change the steering lever's
distance from neutral.
DANGER: Stay at least two mowing widths away from any ditches,
drop-offs, or water. Front wheels can rotate when the mower is
stopped, even with the brake applied, and cause the mower to go over
the edge or into the water and result in death or serious personal injury.
WARNING: Be aware of what is behind the mower before backing
up. DO NOT mow in reverse unless absolutely necessary. Always look
down and behind before and while backing to make sure no children,
bystanders, or pets enter the mowing area. Remember that a careless
fraction of a second is sufficient to inflict death or serious injury.
WARNING: Do not operate this machine on public roadways.
WARNING: If blockage happens or you strike a foreign object, stop
the motors and remove the batteries. Remove grass clippings, leaves,
dirt and any other accumulated debris; thoroughly inspect the mower
for damage and repair the damage before restarting and operating the
mower.
MAINTENANCE
WARNING: Always wear eye protection with side shields. Failure
to do so could result in objects being thrown into your eyes resulting in
possible serious injury.
WARNING: Always protect your hands by wearing heavy gloves
or wrapping the cutting edges with rags or other materials when
performing any maintenance on the mower blade. Always remove the
safety key and battery packs when servicing or transporting the mower.
