17. Side-Discharge Chute
18. Deck-Height Adjustment Lever
19. Seat-Suspension Adjustment Knob
20. Seat Position Adjustment Lever
21. Lap Bars
22. Mower Status Indicator
23. LCD Screen
24. PTO Switch
25. Start/Stop Button
26. Safety Key
27. Phone Storage Slot
28. Baffle Bar
29. Mower Fuel-Gauge & Status Indicator
29a Mower Fuel-Gauge Indicator
29b Mower Status Indicator
30. Foot-Rest Area
31. Power-unit Cover Release Button
32. Power-unit Cover
33. Power unit with six battery compartments
34. Battery-Release Button
35. Hitch
36. Attachment Mounting Cover
37. Attachment Mounting Cover Storage
38. USB Port
KNOW THE LCD SCREEN (Fig. A3)
Refer to the section "MOWER STATUS REFERENCE" and "FAULT CODE
REFERENCE" for more information about the icons and indicators on
the LCD screen.
1. Safety Key Icon
2. LED Lights Icon
3. Auto-Parking Icon
4. USB Icon
5. Blade Speed Indicator
6. Safety Device Status Indicator
7. Hour Meter
8. Vacant Battery Compartment Icon
9. Temperature Icon
10. Occupied Battery Compartment Icon
11. Driving Mode
12. Fault Code Indicator
13. Overload Indicator
14. Low Power Indicator
15. Driving Speed Indicator
16. Load Indicator
17. Fuel Gauge
24
ZERO TURN RIDE-ON MOWER — ZT5200E-L
18. Blade Speed Adjustment Button
19. Set Button
20. Driving Mode Button
21. LED Light Switch
22. Driving Speed Adjustment Button
23 Bluetooth Icon
UNPACKING
NOTICE: Save the packing materials until you have carefully inspected
and satisfactorily operated the product. If any parts in packing list
assembled on the machine please instantly contact EGO service.
NOTICE:: Except the tools in below packing list, all other tools
mentioned in the manuals are just recommended but not provided.
PACKING LIST (Fig. B)
Zero Turn Ride-On
B-1
Mower
B-2 Seat
B-3 Steering Lever
Socket-Head Screws (2
B-4
for backup)
Hex Bolts
B-5
(2 for backup)
RECOMMENDED ACCESSORIES
WARNING: Use only identical replacement parts listed below. Use
of parts that do not meet the original equipment specifications may lead
to improper performance and compromised safety.
PART NAME MODEL NUMBER
Standard Blade AB5200
High Lift Blade AB5201
Mulching Kit ABP5200
Grass Bagger Kit ABK5200-A
Rear Bumper AMB1000
Cargo Box AMG1000
Sun Shade AMS1000
ASSEMBLY
INSTALLING THE SEAT (Fig. C1 & C2)
WARNING: The safety interlock system must not be disconnected
or bypassed. Doing so could cause the mower to operate unexpectedly,
resulting in personal injury.
B-6 Safety Keys
Open-End Wrenches
B-7
(13mm)
B-8 Alley Key
B-9 Wash-Port Quick Coupler
B-10 Operator's Manual
