Beckhoff EJ3314-0090 Dokumentation Seite 66

Inbetriebnahme
Index 1A0n TC TxPDO-Map (für Ch. 1 - 4 (0 ≤ n ≤ 3))
Index Name
(hex)
1A0n:0 TC TxPDO-MapCh.n+1 PDO Mapping TxPDO 1
1A0n:01 SubIndex 001
1A0n:02 SubIndex 002
1A0n:03 SubIndex 003
1A0n:04 SubIndex 004
1A0n:05 SubIndex 005
1A0n:06 SubIndex 006
1A0n:07 SubIndex 007
1A0n:08 SubIndex 008
Index 1A04 RTD TxPDO-Map Inputs Ch.1
Index Name
(hex)
1A04:0 RTD TxPDO-Map
Inputs Ch.1
1A04:01 SubIndex 001
1A04:02 SubIndex 002
1A04:03 SubIndex 003
1A04:04 SubIndex 004
1A04:05 SubIndex 005
1A04:06 SubIndex 006
1A04:07 SubIndex 007
1A04:08 SubIndex 008
Index 1A05 RTD TxPDO-Map Inputs Ch.2
Index Name
(hex)
1A05:0 RTD TxPDO-Map
Inputs Ch.2
1A05:01 SubIndex 001
1A05:02 SubIndex 002
1A05:03 SubIndex 003
1A05:04 SubIndex 004
1A05:05 SubIndex 005
1A05:06 SubIndex 006
1A05:07 SubIndex 007
1A05:08 SubIndex 008
66
Bedeutung
1. PDO Mapping entry (object 0x60n0 (TC Inputs Ch.
(n+1)), entry 0x01 (Underrange))
2. PDO Mapping entry (object 0x60n0 (TC Inputs Ch.
(n+1)), entry 0x02 (Overrange))
3. PDO Mapping entry (4 bits align)
4. PDO Mapping entry (object 0x60n0 (TC Inputs Ch.
(n+1)), entry 0x07 (Error))
5. PDO Mapping entry (7 bits align)
6. PDO Mapping entry (object 0x60n0 (TC Inputs Ch.
(n+1)), entry 0x0F (TxPDO State))
7. PDO Mapping entry (object 0x60n0 (TC Inputs Ch.
(n+1)), entry 0x10 (TxPDO Toggle))
8. PDO Mapping entry (object 0x60n0 (TC Inputs Ch.
(n+1)), entry 0x11 (Value))
Bedeutung
PDO Mapping TxPDO
1. PDO Mapping entry (object 0x6040 (RTD Inputs Ch.1),
entry 0x01 (Underrange))
2. PDO Mapping entry (object 0x6040 (RTD Inputs Ch.1),
entry 0x02 (Overrange))
3. PDO Mapping entry (4 bits align)
4. PDO Mapping entry (object 0x6040 (RTD Inputs Ch.1),
entry 0x07 (Error))
5. PDO Mapping entry (7 bits align)
6. PDO Mapping entry (object 0x6040 (RTD Inputs Ch.1),
entry 0x0F (TxPDO State))
7. PDO Mapping entry (object 0x6040 (RTD Inputs Ch.1),
entry 0x10 (TxPDO Toggle))
8. PDO Mapping entry (object 0x6040 (RTD Inputs Ch.1),
entry 0x11 (Value))
Bedeutung
PDO Mapping TxPDO
1. PDO Mapping entry (object 0x6050 (RTD Inputs Ch.2),
entry 0x01 (Underrange))
2. PDO Mapping entry (object 0x6050 (RTD Inputs Ch.2),
entry 0x02 (Overrange))
3. PDO Mapping entry (4 bits align)
4. PDO Mapping entry (object 0x6050 (RTD Inputs Ch.2),
entry 0x07 (Error))
5. PDO Mapping entry (7 bits align)
6. PDO Mapping entry (object 0x6050 (RTD Inputs Ch.2),
entry 0x0F (TxPDO State))
7. PDO Mapping entry (object 0x6050 (RTD Inputs Ch.2),
entry 0x10 (TxPDO Toggle))
8. PDO Mapping entry (object 0x6050 (RTD Inputs Ch.2),
entry 0x11 (Value))
Version: 1.1
Datentyp Flags Default
UINT8 RW 0x08 (8
dez
UINT32 RW 0x60n0:01, 1
UINT32 RW 0x60n0:02, 1
UINT32 RW 0x0000:00, 4
UINT32 RW 0x60n0:07, 1
UINT32 RW 0x0000:00, 7
UINT32 RW 0x60n0:0F, 1
UINT32 RW 0x60n0:10, 1
UINT32 RW 0x60n0:11, 16
Datentyp Flags Default
UINT8 RW 0x08 (8
dez
UINT32 RW 0x6040:01, 1
UINT32 RW 0x6040:02, 1
UINT32 RW 0x0000:00, 4
UINT32 RW 0x6040:07, 1
UINT32 RW 0x0000:00, 7
UINT32 RW 0x6040:0F, 1
UINT32 RW 0x6040:10, 1
UINT32 RW 0x6040:11, 16
Datentyp Flags Default
UINT8 RW 0x08 (8
dez
USINT8 RW 0x6050:01, 1
INT16 RW 0x6050:02, 1
UINT32 RW 0x0000:00, 4
INT16 RW 0x6050:07, 1
UINT32 RW 0x0000:00, 7
INT16 RW 0x6050:0F, 1
INT16 RW 0x6050:10, 1
INT16 RW 0x6050:11, 16
EJ3314-0090
)
)
)
