Start-up
• Attach the double-sided adhesive
strip to the rear of the electronic
unit (B) and press the electronic
unit onto the desired position of
the window/door frame.
1
3
Figure 5
Make sure that the installation
surface is smooth, solid, undam-
aged, free of dust, grease and
solvents and not too cold to en-
sure that the adhesive strip will
adhere for a long time.
Screw installation
Using screws will damage the
window and/or door. For those
living in rented accommodation,
this could lead to a landlord mak-
ing a claim for compensation or
holding back a tenant's deposit.
2
4
Proceed as follows to install the win-
dow and door contact with the screws:
• Mark the bore holes (A) on the win-
dow and door frame.
1
Figure 6
• If you are working with hard sur-
faces, pre-drill the holes marked
using a 1.5 mm drill (not necessary
for soft surfaces).
• Place the electronic unit (B) on
the desired installation location
and screw both countersunk head
screws into the bore holes (A).
Figure 7
2
2x
19
