Adjustments
5.3 Adjustment of the height adjustable support (accessory)
When using the device in batch operation, for gripping of single stone slabs (batched one upon the
other), we advise to use the accessory "height adjustable support" HVA-FTZ/TSZ (see figure).
Therefore, the inside height must not always be adjusted again for gripping goods with the same
dimensions.
When picking up in batch operation the top stone slab
may only be lifted!
• The height adjustable support (B) is attached to the
mounting plate (A)
Adjust the height adjustable support (B) with the
•
adjusting screws and make sure that both parts have
the same height and that the rubber gripper bars are
positioned in the middle area of stone thickness.
53100348 19 / 29
Fig. 1
