The NeoSoft Connect can be adapted to all SYR flanges DN 20 - 32.
If a pressure reducer-filter combination (e.g. SYR Drufi +) is already present, the installation does not need to be changed. The filter is
simply placed on the NeoSoft connection flange
You can connect the NeoSoft to the power supply before you start the installation.
The necessary steps for installation and commissioning can be found in the instructions on the display.
•
Mount the NeoSoft connection flange on the universal flange already installed.
•
Connect the armored hose
•
Connect the armored hose to the housing on the back of the NeoSoft 2500 Connect (armored hose
D
at the outlet) and secure the hoses with the clamps.
(see pages 5 &
6).
A
to the NeoSoft connection flange and secure the hose with the clamp
D
Please note the direction of flow. It is indicated
by an arrow on the housing.
B
B
A
C
C
.
at the inlet and armored hose
