effeff ePED Hi-O Technology Bus Installationsanleitung Seite 32

Fig. 6:
Hi-O Technology™
Distributor
901-Hub-01
EN
32
V +
B
GND
1 CAN_H
2 CAN_L
3 V +
B
4 GND
1 CAN_H
2 CAN_L
3 V +
B
4 GND
1 CAN_H
2 CAN_L
3 V +
B
4 GND
1 CAN_H
2 CAN_L
3 V +
B
4 GND
901-Hub-01
Protection class
Operating voltage
J1
J11
4 GND
3 V +
X6 X2
B
2 CAN_L
1 CAN_H
4 GND
3 V +
X7 X3
B
2 CAN_L
1 CAN_H
4 GND
3 V +
X8 X4
B
2 CAN_L
1 CAN_H
4 GND
3 V +
X9 X5
B
2 CAN_L
1 CAN_H
IP20
Max. 24 V / 4 A
J1
Connection for
testing device
X2 to X9
Hi-O connections
J10
Power supply
J11
Terminating resistor
(activate with a
jumper)
