effeff ePED Hi-O Technology Bus Installationsanleitung Seite 31

Tab. 10 :
Hi-O Technology™
door wiring with
distributor and
remote IO
interface
Hi-O Technology™ –
Door wiring with distributor
Maximum total line length
Maximum single line length
Maximum branch connection line length 10 m
Minimum cable cross-section
Terminating resistor
Topology
Remote IO interface
Connection
Maximum total line length
Maximum branch connection line length 0.1 m
Minimum cable cross-section
Terminating resistor
Topology
Line requirements
Measures for interference suppression Unilateral earthing of cable shield
50 m
10 m
0.5 mm²
120 Ω, activate at distributor
Star form to distributor
CAN bus without power supply
300 m
0.5 mm²
120 Ω, activate at the distributor and
at the remote IO interface
Linear topology
CAN bus certified or
I-Y(St)Y 2 x 2 x 0.8
