Product information
Hi-O Technology™ Bus
The Hi-O Technology™ bus (Highly Intelligent Opening) is a bus for the connection
of electronic components (devices) in door systems. It is used for the control of
one door The status monitoring and exchange of information between the
individual devices takes place via a CAN bus.
A central logic controller can be omitted, because each device has its own control
unit. In escape route technology, it consists of a closed system with permanently
assigned bus addresses.
www.assaabloy.de
Solutions/
All devices are interconnected via four-core cables. Conventional devices can be
The intelligent door/
connected via I/O boxes. Integration into a building network (Ethernet) or the
Hi-O
interaction of multiple doors takes place via a gateway (e.g. an Ethernet gateway).
The Hi-O Technology™ bus offers
· Easy wiring,
· Easy planning,
· Easy extensions,
· Low installation expenses and
· Ease of maintenance
