Product information
Further information
For further information concerning this product, please see Printed Matter No. 9836 7056 00, available in
ServAid on the web.
Overview
Applications
Human machine interface, serving:
■
Supervision of the tightening process.
■
Guidance to the operator.
Main components and functions
Maxidispaly 3 is a PC, built in a 19 inch touch screen. It is equipped with a Vesa standard mounting. It is
powered by a separate 19 V / 4.74 A power adapter. A number of connectors as well as WLAN is avail-
able for connection to external equipment.
Technical data
CPU
RAM-Memory
Harddrive
LAN 1
LAN 2
WiFi
Display
Size (WxHxD)
Mounting
Weight
Power supply
EMC/Safety
Front class
Operating temperature
Relative operating humidity
Software
Service intervals
Service recommendations
Overhaul and preventive maintenance is recommended at regular intervals. See the Preventive mainte-
nance section for detailed information regarding overhaul of your tool and specific parts. If the machine is
not working properly, it should immediately be taken away for inspection. At the overhauls, all parts should
be cleaned accurately and defective or worn parts should be replaced.
4
EN
© Atlas Copco Industrial Technique AB - 9836 7057 00
Intel i5-2390T 2.7 GHz
4 GB, DDR3, 1333 Mhz
Serial ATA, 300MB/s transfer rate, 2,5" 160 GB
Gigabit Intel 82579LM
Gigabit Intel WG82583V
802.11 b/g/n
19" TFT Resistive, 1280*1024 SXGA
449 x 389 x 62 mm
Vesa standard, 100 x 100 mm
11 kg (wallmount not included)
Power Adapter DC 19 V / 4.74 A
FCC Class A, CE
IP65
0 to 40 °C
5 – 95% (non-condensed)
Microsoft Windows 7 Professional
