English (GB) Installation and operating instructions
Original installation and operating instructions
CONTENTS
1.
Symbols used in this document
2.
General information
2.1 Delivery contents
2.2 Application
2.3 Avoidance of danger
2.4 Nameplate
3.
Construction and function
3.1 System overview
3.2 Installation and operating instructions
3.3 Keypad overview
3.4 LED indicators
3.5 DIT-IR power supply
3.6 DIT-IR connection
4.
Installation of the device driver and data acquisition
software
4.1 Driver installation
4.2 Software installation
5.
Start the application
5.1 Data transmission
5.2 Serial interface mode
5.3 PC interface mode
6.
Disposal
Warning
Prior to installation, read these installation and
operating instructions. Installation and operation
must comply with local regulations and accepted
codes of good practice.
1. Symbols used in this document
Warning
If these safety instructions are not observed, it may
result in personal injury.
If these safety instructions are not observed, it may
Caution
result in malfunction or damage to the equipment.
Notes or instructions that make the job easier and
Note
ensure safe operation.
4
2. General information
These installation and operating instructions contain all
information important for users of the DIT-IR infrared interface
Page
module.
4
Should you require further information, or should you encounter
problems that are not described in sufficient depth in this manual,
4
please contact Grundfos.
4
4
2.1 Delivery contents
4
5
Carefully inspect all items to ensure that every part of the list
below is present and no visible damage has occurred during
5
shipment.
5
If there is any damage or missing items, please contact your local
5
distributor immediately.
5
5
A DIT-IR standard delivery comprises:
5
•
1 DIT-IR module in a plastic case
6
•
4 batteries (type AA/LR6)
•
1 USB cable
6
•
1 screwdriver with clip, red
6
•
1 installation and operating instructions
7
•
1 certificate of compliance.
7
7
2.2 Application
7
8
The DIT-IR infrared interface module is suitable for transferring
data from a DIT-L or DIT-M photometer to a PC.
9
2.3 Avoidance of danger
Warning
Do not open or dismantle the module!
Cleaning, maintenance and repair must only be
carried out by authorised personnel!
If safe operation cannot be ensured any longer, the DIT-IR
infrared interface module is to be taken of service and
safeguarded against unintentional operation. This is the case
under the following circumstances:
•
The DIT-IR module has visible damage.
•
The DIT-IR module seems to be inoperative.
•
After a long storage time under unfavourable circumstances.
