8.3 Fitting the spacer roller (11) (Fig.
3, 8)
Lawn edge trimming:
1. Attach the spacer roller (11) to the motor head (15).
It engages audibly.
Cutting grass / transporting the product:
1. Attach the spacer roller (11) to the protective cover
(12).
You will hear it click into place.
9 Operation
The hand-held and portable cordless strimmer has a
cutting device with a thread coil with fully automatic ad-
justment. The product is also equipped with an adjust-
able tilt angle, adjustable telescopic tube and a spacer
bar. To protect the user, the product is fitted with a pro-
tective cover that covers the cutting device.
WARNING
Danger of injury!
Remove the battery from the power tool before carry-
ing out any work on the power tool (e.g. maintenance,
tool change, etc.) and when transporting and storing
it. There is a risk of injury if the on/off switch is oper-
ated unintentionally.
WARNING
Check the safety equipment regularly before each
start-up. Faulty safety equipment can cause serious
injuries!
ATTENTION
Make sure that the ambient temperature does not ex-
ceed 50°C and does not fall below -20°C during work.
ATTENTION
The product is part of the 20V gomag series and may
only be operated with batteries of this series. Batter-
ies may only be charged with battery chargers of this
series. Observe the manufacturer's instructions.
9.1 Inserting/removing the battery
(19) into/from the battery mount
(8) (Fig. 4)
Inserting the battery
1. Push the battery (19) into the battery mount (8). The
battery (19) clicks into place audibly.
Removing the battery
1. Press the unlock button (20) of the battery (19) and
remove it from the battery mount (8).
24 | GB
9.2 Switching the product on/off (Fig.
1)
Switching on
Notes:
Before switching on, make sure that the product does
not touch any objects.
Note:
• Always hold the product tight with both hands
during work. Make sure that you have a secure
footing.
• Remain attentive at all times when working, and
keep third parties at a safe distance from your work
area.
1. To switch on, press the switch lock (2) and then
press the on/off switch (9).
Note:
It is not necessary to keep the switch lock pressed after
starting the product. The switch lock is intended to pre-
vent accidental starting of the product.
Switching off
1. To switch off, release the on/off switch (9).
Continuous operation is not possible.
CAUTION
After switching off, the product will run on. Wait until
the product has come to a complete stop.
9.3 Overload protection
Note:
In the event of overloading, the motor will switch itself
off. After a cool-down period (time varies) the motor can
be switched back on again.
9.4 Settings on the product
9.4.1
Notes:
You can move the additional handle to various different
positions.
Adjust the additional handle so that the coil capsule is
tilted slightly forwards in the working position.
ATTENTION
Only use the product with the additional handle fitted.
1. Press the pushbutton (7) on the additional handle
(3). Hold it down to adjust the additional handle (3).
2. To lock the additional handle (3) in place, release
the push button (7).
The locking detents integrated in the holder secure
the additional handle (3) and prevent it from moving
unintentionally.
www.scheppach.com
Adjusting the additional handle (3)
(Fig. 5)
