Note:
The additional handle can be rotated 360° on the prod-
uct and can be moved to any desired/needed position.
1. To do this, loosen the two Phillips screws (3a) on
the additional handle (3).
Use the Phillips screwdriver supplied.
2. Turn the additional handle (3) to the desired posi-
tion.
3. Tighten the two Phillips head screws (3a) again.
9.4.2
Adjust the height (Fig. 1)
Note:
The telescopic tube allows you to adjust the product to
suit your individual size.
1. Loosen the threaded sleeve (4).
2. Adjust the telescopic tube (5) to the desired length
and tighten the threaded sleeve (4) again.
9.4.3
Adjusting the cutting angle (Fig. 6)
By changing the cutting angle, you can also trim in in-
accessible places, e.g. under benches and protrusions.
6 positions are possible.
1. Loosen off the locking device (10) on the motor
head (15)
and tilt the telescopic tube (5).
2. Tighten the locking device (10) again
locking device (10) in place.
Function as a strimmer:
Cutting angle positions 1 – 5
Function as a lawn edge trimmer:
Cutting angle position 6
9.5
Replacing the thread coil (16)
(Fig. 1, 7)
1. Open the coil capsule (6) by simultaneously press-
ing the two release buttons (6a) on the coil capsule
(6).
2. Remove the cover (6b) of the coil capsule (6) and
remove the thread coil (16).
3. Pull the thread end of the thread coil (16) out of the
thread outlet eyelet (18).
4. Thread the thread end of the new thread coil (16)
through the thread outlet eyelet (18).
5. Insert the new thread coil into the coil capsule (6).
The side of the thread coil on which the running di-
rection is indicated by arrows must be visible after
insertion.
6. Press the locking button (17). The detents integrat-
ed in the coil capsule (6) slide into the detents of the
thread coil (16) and prevent unintentional adjust-
ment.
7. Replace the cover (6b) on the coil capsule (6).
Make sure that the release catches (6a) on the cov-
er (6b) fit exactly into the recesses on the coil cap-
sule (6). You can hear them click into place.
8. Pull the thread end and keep pressing the locking
button (17) until the thread end protrudes approx. 1
cm beyond the thread cutter (14).
9.6
Lengthening the cutting thread
(Figs. 1, 7)
Your product is equipped with a fully automatic cutting
thread.
The thread is automatically extended each time the ma-
chine is switched on. For the automatic thread exten-
sion system to function correctly, the thread coil (16)
must have come to a standstill before you switch on the
product.
If the thread is initially longer than the cutting circle
specified, it is automatically shortened to the correct
length by the thread cutter (16).
Note:
Check the nylon thread regularly for damage and
whether the cutting thread is still the length specified by
the thread cutter.
If no thread end is visible:
1. Replace the thread coil (16) as described under Re-
placing the thread coil (16) (Fig. 1, 7).
Set the thread length manually:
1. Pull lightly on the thread end and press the locking
to lock the
button (17), several times if necessary, until the
thread end protrudes slightly beyond the thread cut-
ter (16).
10 Working instructions
Note:
Some noise pollution from this product is unavoidable.
Postpone noisy work to approved and designated
times. If necessary, adhere to rest periods.
• Hold the product with both hands during the work.
Grasp both handles.
• Do not use the product in a thunderstorm - Danger
of lightning strike!
• Check the product for obvious defects such as
loose, worn or damaged parts before each use.
• Switch on the product and only then approach the
material to be processed.
• Do not exert excessive pressure on the product. Let
the product do the work.
• Grass is best cut when it is dry and not too long.
• Avoid contact with solid obstacles (stones, walls,
fences, etc.).
10.1
Cutting grass (Fig. 8)
Note:
The spacer roller is not required for grass cutting.
1. Attach the spacer roller (11) to the protective cover
(12).
You will hear it click into place.
www.scheppach.com
GB | 25
