25.6.2.2 Warning and Safety Notices
Removal of the plug-in module on the upper plug-slide mechanism
of the device:
Please do not reach into the area around the scanner glass of the
main device; there is a risk of injury due to pinching when sliding.
CAUTION
The scanner glass can also be soiled in the process.
The maximum permissible ambient temperatures for the modules
are listed below.
Operating temperature:
Storage temperature:
CAUTION
The device has the following radio system:
UHF-RFID
Frequency band:
CAUTION
Max. permissible transmission power on the frequency band:
The M2UHF-RFID Shortrange attachable module can become very
hot during extended operation. To protect persons and the
module, the maximum time of a scan is limited to two minutes.
CAUTION
25.6.2.3 Handling
After the M2UHF-RFID Shortrange attachable module has been plugged into the main device on the upper
plug-slide mechanism, it can be used for reading UHF-RFID tags.
To do this, start a software application to initialize the module. Then the read process can be carried out with
the software application.
25.6.2.4 Technical Data M2UHF-RFID Shortrange
The table below includes the technical data for the M2UHF-RFID Shortrange plug-in module.
Housing
Protection class
Operating
temperature
Storage temperature
Rel. humidity
Device dimensions
Weight
Interfaces
Frequency range EU
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.20_de_en
 UHF-RFID
Europe:
USA and Canada: 902.75 MHz to 927.25 MHz
 UHF-RFID 200 mW
ABS/PC
IP65
-20 °C to 50 °C/-4 °F to 122 °F
Condensation of the device must be avoided.
-20 °C to 60 °C/-4 °F to 140 °F
5 % - 90 % non-condensing
52 x 85 x 27 mm (L x W x H)
58 g
Plug for connection to the main device
865.7 MHz to 867.5 MHz
-20 °C to 50 °C/-4 °F to 122 °F
-20 °C to 60 °C/-4 °F to 140 °F
865.7 MHz to 867.5 MHz
Technical Data
