25.6 The individual modules in detail

25.6.1 M2Key16 Logistics

The M2Key16 Logistics is described below. It is a hard case keyboard with 16 keys, which can be used for
the lower plug-in sliding mechanism.
Fig. 68: M2Key16 Logistics keyboard module
25.6.1.1

Scope of Delivery

The following components are included in the scope of delivery of the M2Key16 Logistics:
 M2Key16 Logistics plug-in module
 Brief overview
The scope of delivery described above can vary and depends on the corresponding PO.
Please check the package content directly after receipt to ensure that it is complete and undamaged. If a
shipment is incomplete or damaged, please report this immediately to the responsible office at your
company.
25.6.1.2

Warning and Safety Notices

The maximum permissible ambient temperatures for the modules
are listed below.
Operating temperature:
Storage temperature:
CAUTION
Do not bring the device into contact with liquids and do not empty
any liquids onto the device.
CAUTION
25.6.1.3

Handling

After the M2Key16 Logistics module has been plugged into the main device on the lower plug-slide
mechanism, it can be used for keyboard inputs.
The default configuration is described below:
The second keyboard level (orange marked F-keys) is activated by pressing the Fn key and then the desired
F-key within 3 seconds. The activation of the second keyboard level is indicated by the LED on the Fn key,
which lights up red.
After pressing the F-key, the first keyboard level is activate again. If no F-key is pressed, the function of the
Fn key goes out automatically after 3 seconds.
®
