ACD M2Smart SE Set Kurzübersicht Seite 64

The third keyboard level (green marked keys) is activated by pressing the Fn key (from level 1 press twice,
from level 2 press once) and then pressing the desired letter key within 3 seconds. The activation of the third
keyboard level is indicated by the LED on the Fn key, which lights up green.
The desired letter can be selected by repeatedly pressing the corresponding key, as in the familiar T9
keyboard. The selection is shown on the display.
The described behavior can be configured in wide parts, especially characters can be replaced. Details can
be found in the documentation
Android_de_en".
It is not possible to charge the M2Smart
plugged in.
Type
Number of keys
Layout
1st keyboard level
Layout
2nd keyboard level
Layout
3rd keyboard level
25.6.1.4 Status LEDs
The status LEDs of the module will be described below.
Fn-LED flashes red:
Fn-LED lit red:
Fn-LED lit green:
®
M2Smart SE_Set_Kurzübersicht_Brief Overview_V1.20_de_en
„Tastaturkonfiguration-unter-Android_Keyboard-Configuration-under-
®
SE in the docking station when the M2Key16 Logistics keyboard is
Hard shell keyboard
16 keys,
10 function keys,
3 keyboard levels
0 to 9, Enter, S, C, Fn, ↑, ↓
Fn, F1 – F10,„ , ", Enter, S, ↑, ↓
Blank, a to z, „ . ", a -> A, Enter, S, ↑, ↓
The Fn LED flashes red for a short time and then green when the module is
plugged in.
The Fn LED lights up red when the Fn key is pressed once. It goes out when
another key entry is made. If no key entry is made, the Fn LED goes out after
3 seconds.
The Fn LED lights up green when the Fn key is pressed (press twice from
level 1, press once from level 2). It only goes out again after the Fn key is
pressed again or after 3 seconds.
After a keyboard entry, the third keyboard level (Fn LED lights up green)
remains active until the Fn key is pressed again.
Tastatur
64 / 76
