2.9. Calibration

3.2.1. Soldering temperature calibration
1. Set the temperature of the soldering station to
350℃.
2. When the temperature is stable, use the soldering
iron temperature tester to measure the tip temperature and write down
the readings.
3. Press and hold the "+" button and "
soldering station enters into the temperature calibration mode.
4. Press the "
soldering station.
5. Long press the "
Note: It is recommended to use QUICK 191/192 series temperature tester to
measure tip temperature.
3.2.2. Hot air temperature calibration
1. Set the hot air temperature to 300℃ calibration.
2. Press and hold "
enter the hot air temperature calibration mode.
3. When the temperature is stable, use the hot air temperature tester to
measure the hot air temperature, press "+" or "–".
4. Change the hot air temperature, press and hold "+" and "-" to confirm,
and return to the main screen.
Note: It is recommended to use QUICK 196 series hot air temperature tester
to measure hot air temperature.
" or " " button to change the temperature of the
" and " " button to save.
" and "-" at the same time to
" button at the same time. The
