2.5.

Applications

1. It is suitable to the de-soldering of the SMD components, such as SOIC,
CHIP, QFP, PLCC, BGA and so on.
2. It is suitable to hot shrink, drying, remove lacquer and mucosity, thaw,
preheating, disinfect and so on.
3. It is suitable for the situation needing different range airflow, softer or
heavier.
4. It is suitable for the hot air lead free de-soldering.

2.6. Operation Instruction

The tray for the hot air pen must be mounted on the
station. To do this, 2 screws on the side of the station
must be loosened slightly. Then the holder can be
inserted and the 2 screws tightened.
ATTENTION: Before switching on, check whether the
operating voltage corresponds to the voltage specified
on the type plate!
Make sure that the station is always switched off when plugging or unplugging
the soldering iron. Failure to do so may result in damage.
5
