surface. Important! Place suitable material
(e.g. packaging material) between the table
surface and the surface on which it is stood to
prevent any damage to the table surface.
•
Important! Only fasten all the screw connec-
tions between the base frame and machine
loosely at first. Wait until you have returned
the bench-type circular saw to its working po-
sition before tightening the screw connections
securely. This is so that you can be sure the
base frame is aligned level with the surface
on which it is stood.
•
Use the hexagon screws (43) to fasten the
four legs (29) loosely to the saw.
•
Then, using the hexagon screws (43) and the
nuts (44), fasten the longitudinal struts (31)
and the cross-struts (30) loosely to the legs.
Make sure that the shorter struts (30) are fas-
tened to the side of the saw.
•
Plug the rubber feet (13) onto the legs (29).
6.2 Standing the bench-type circular saw up-
right (Fig. 2, 6-9)
•
Turn the machine over so that it stands on its
legs.
•
The bench-type circular saw must be stood
on a flat surface.
•
Then tighten all loose screw connections. Use
both the wrenches (38) and (39) to do this.
•
Screw the additional legs (37) to the rear legs
(29) so that they point towards the rear of the
machine. Use the hexagon screws (43) and
the nuts (44) to fasten them.
•
Warning! Don not fit the additional legs (37)
too far away from the surface on which the
machine stands; they are intended to provide
protection against tipping over.
•
Fit the socket head screw (45) with the two
nuts (46) to the front right leg (29). This is
used as a holder for the push stick (3).
•
To enable the machine to be used with the
suction hose (10), the cap (36) on the saw
blade guard (2) must be removed first. To
do this, undo the screw using a crosstip
screwdriver.
•
Then connect the saw blade guard (2) and
the side connection of the extractor adapter
on the housing (16) to the suction hose (10).
•
A crosstip screwdriver and hex key are not
supplied with the product.
GB
6.3 Changing the table insert (Fig. 10, 12)
•
To prevent increased likelihood of injury, the
table insert should be changed whenever it is
worn or damaged.
•
Take off the saw blade guard (2) (see 6.5).
•
Remove the countersunk head screw (17).
•
Take out the worn table insert (6).
•
Fit the replacement table insert by following
the above in reverse.
6.4 Fitting/replacing the splitter (Fig. 11, 12)
•
Using the hand wheel (8), set the blade (4) to
max. cutting depth, move to 0° position and
lock in place.
•
Remove the saw blade guard (2) (see 6.5).
•
Take out the table insert (6) (see 6.3).
•
Slacken the fastening screw (19) until the gap
between the fastening plate (40) and the sup-
port surface opposite is approx. 5 mm.
•
Caution! Do not completely undo the faste-
ning plate (40).
•
Insert the splitter (5) in the gap, push it right
down as far as it goes and then secure it
with the fastening screw (19). Make sure that
the splitter has been fitted straight and not
wobbly.
•
The splitter (5) must be positioned in the cen-
ter along an imaginary line extending behind
the saw blade (4), so that it is not possible for
the material to get jammed.
•
The gap between the blade (4) and the split-
ter (5) should be 3 mm to 8 mm. (Fig. 11c).
•
Refit the table insert (6) and the saw blade
guard (2) (see 6.3, 6.5)
6.5 Fitting/changing the saw blade guard
(Fig. 13)
•
Mount the saw blade guard (2) on the splitter
(5) so that the screw fits through the hole (18)
in the splitter.
•
Then insert the screw on the saw blade guard
(2) through the hole (18) and tighten it.
•
Important! The maximum depth that the
screw can be screwed in has been preset at
the factory, so that the saw blade guard (2) is
always able to move freely.
•
Warning! The saw blade guard (2) must al-
ways lower to the workpiece automatically
under its own weight.
6.6 Fitting/changing the saw blade (Fig. 14)
•
Before changing the saw blade: Pull out the
power plug!
•
Wear work gloves to prevent injury when
changing the saw blade.
