Using the hand wheel (8), set the saw blade
(4) to the maximum cutting depth.
•
Remove the saw blade guard, table insert
and splitter (see 6.5, 6.3, 6.4)
•
Undo the screw (15) with a wrench (38) on
the screw (15) itself and a second wrench
(39) on the motor shaft to apply counter-
pressure.
•
Caution! Turn the screw (15) in the direction
of rotation of the saw blade.
•
Take off the outer flange and pull the old saw
blade (4) off the inner flange.
•
Clean the blade flange thoroughly before fit-
ting the new blade.
•
Fit and fasten the new saw blade (4) in rever-
se order.
•
Important! Note the running direction. The
cutting angle of the teeth must point in run-
ning direction, i.e. forwards (see the arrow on
the blade guard).
•
Refit and set the splitter, table insert and saw
blade (see 6.4, 6.3, 6.5).
•
Check to make sure that all safety devices
are properly mounted and in good working
condition before you begin working with the
saw again.
•
Warning! Every time that you change the saw
blade, check that the saw blade guard (2)
opens and closes again in accordance with
requirements. Also check that the saw blade
(4) spins freely in the saw blade guard (2).
•
Warning! Every time that you change the saw
blade (4), check to see that it spins freely in
the table insert (6) in both perpendicular and
45° angle settings.
•
Warning! You should replace the table insert
(6) immediately whenever it is worn or dama-
ged (see 6.3).
•
Warning! The work to change and align the
saw blade (4) must be carried out correctly.
6.7 Putting away loose parts (Fig. 15)
•
When not in use, the parallel stop (7) and
stop rail (23) can both be secured as shown
in Fig. 15a.
•
The cross stop (14), push stick (3) and the
two wrenches (38+39) can be secured as
shown in Fig. 15b.
6.8 Connection for dust extractor
(Fig. 2, 9, 26)
A connection for a dust extractor is provided on
the extractor adapter on the housing (16) and on
the saw blade guard (2).
GB
6.8.1 Dust extraction using a wet & dry vac
(Fig. 2, 9)
•
A wet & dry vac is not supplied with the pro-
duct and is available as an accessory.
•
Attach the suction hose (10) to the machine
as described in 6.2.
•
Connect the wet & dry vac to the extractor
adapter on the housing (16).
6.8.2 Dust extraction using a vacuum ext-
raction system and extractor adapter set
(Fig. 9, 26)
•
The product is not supplied with an extractor
adapter set or a vacuum extraction system,
which are available as accessories.
•
Attach the suction hose (10) to the machine
as described in 6.2.
•
Attach the adapter (c) of the adapter set to
the extractor adapter on the housing (16).
•
A vacuum extraction system can now be
connected to the 100 mm diameter of the
adapter (c).
7. Operation
7.1 ON/OFF switch (Fig. 1, 16 / Item 11)
•
To turn the saw on, press the green button
„I". Wait for the blade to reach its maximum
speed of rotation before commencing with
the cut.
•
To turn the equipment off again, press the red
button „0".
7.2 Cutting depth (Fig. 1, 16)
Turn the hand wheel (8) to set the blade (4) to the
required cutting depth.
Turn anti-clockwise:
smaller cutting depth
Turn clockwise:
larger cutting depth
7.3 Parallel stop
The parallel stop (7) has to be used when making
longitudinal cuts in wooden workpieces.
7.3.1 Stop height (Fig. 18, 19)
•
The parallel stop (7) supplied with the bench-
type circular saw has two different guide
faces.
•
For thin material you must use the stop rail
(23) as shown in Fig. 19a, for thick material
