ASSEMBLING YOUR SHARK® KLIK N' FLIP
AUTOMATIC STEAM MOP
WARNING: Always
make sure the Steam
Mop is UNPLUGGED
when not in use. Never
fill the Steam Mop or
attach the mop head
when the Steam Mop
is plugged into an
electrical outlet. Unplug
from the electrical outlet
and allow to cool before
you fill the Steam Mop,
or attach or remove the
head. To prolong the
life of your Steam Mop,
we recommend using
distilled water. Make
sure you add only water
to the tank. Adding
chemicals or cleaning
solutions (including
vinegar) will void your
warranty and may
damage the Steam Mop
and could be unsafe for
you and your family.
1 Insert the Steam Mop
handle into the Steam
Mop body. Push the
handle in until you
hear it click into place.
43
2 Slide the Klik n' Flip
Mop Head into the
Steam Mop body.
Push until you hear
it click securely into
place. To detach the
Klik n' Flip Mop Head,
press the release
button and slide off.
FIG�2
FIG�1
3 To attach the Dirt corner tabs into the
Grip Pad, spread the four corner pockets
of the pad (FIG� 3)
pad on the floor with
the pocket side up. Gently press one side
Center the Klik n' Flip of the Klik n' Flip Mop
Mop Head above the Head to the floor until
pad (FIG� 1), then
that side clicks into
place. (FIG� 4) Repeat
press the pad release
button on the back of on the other side.
the Steam Mop body. (FIG� 5)
(FIG� 2) Both sides of
the Klik n' Flip Mop
Head will drop open.
(FIG� 3) Slip the Klik n'
Flip Mop Head's four
FIG�3
FIG�4
FIG�5
4 Pull down on the
water tank lid to open.
5 Use the filling flask to
pour water into the
water tank. Water can
be poured into the
tank directly. Do not
overfill past the water
line on the fill flask.
Press the water tank
lid firmly to close it.
44
