Nozzle guard (4) is loose.
Spray tip (5) is worn.
Material leaking
Seal inside the nozzle guard (4) is
worn.
Material building up spray tip (5) and
nozzle guard (4).
Material volume too large.
Atomization is too
coarse.
Spray Tip and Nozzle Guard clogged.
Suction hose mesh filter (12) clogged.
Pattern runs or
Applying too much material
sags.
Gun too far from spray object.
Too much over-
spray.
Too much material applied.
Pattern is very light
Moving the spray gun (6) too fast.
and blotchy.
Spluttering paint. Air bubbles in the return hose (10).
Suction Hose (11)
not sucking up wa-
Lack of pressure.
ter when cleaning
the unit.
Tighten the nozzle guard (4).
Replace the spray tip (5).
Replace the sealing (28).
Clean spray tip (5) and nozzle guard (4) by using
the appropriate cleaning solution depending on
the material used.
Decrease pressure control dial (9) setting.
Clean.
Clean or replace.
Adjust pressure control dial (9) or increase move-
ment of spray gun (6).
Reduce distance.
Decrease Pressure control dial (9) setting.
Adjust pressure control dial (9) or decrease move-
ment of spray gun (6).
Perform "priming the pump" steps.
Using the appropriate cleaning solution in place of
material, perform the "priming the pump" steps.
