Legende
Anschlüsse
Digitale Eingänge
Ohne Funktion
DIP-Schalter zur Terminierung der RS-485-Schnittstelle
Serielle Schnittstelle RS-485
Ohne Funktion
Relaisausgang für interne Gerätefehler und Anschlussfehler
Relaisausgang für Alarm Isolationsfehler
Relaisausgang für Alarm Isolationsfehler
Separate Anschlüsse von E (Erde) und KE (Kontrollerde) an PE
Versorgungsspannung U
DC 24 V
s
Ankopplung Klemme L1/+
Ankopplung Klemme L2/–
Ohne Funktion
Rücksetzen von Alarmen
Anschluss Vorgehen
1. Klemme E und KE an Erde (PE) anschließen.
2. Klemme A und B an BMS-Bus anschließen.
3. Klemme S an den Schirm der Bus-Leitung anschließen
(nur an einem Ende der Leitung).
4. Klemme L1/+ an L1/+ des IT-Netzes anschließen
(mit je 1 A-Sicherung).
5. Klemme L2/– an L2/– des IT-Netzes anschließen
(mit je 1 A-Sicherung).
6. Klemme A1/A2 an die Versorgungsspannung U
anschließen (mit je 6 A-Sicherung).
7. Meldeausgänge 11/12/14, 21/22/24 und 31/32/34
anschließen.
Legend
Klemme/Terminal
Digital inputs
I1–, I1+
I2–, I2+
No function
CAN1, CAN2
DIP switch for the termination of the RS-485 interface
RS-485 Term.
Serial RS-485 interface
A, B, S
No function
k, l, kT, lT
Relay output for internal device errors and connection faults
31, 32, 34
Relay output for alarm insulation fault
21, 22, 24
Relay output for alarm insulation fault
11, 12, 14
Separate connections of E (earth) and KE (control earth) to PE
E, KE
Connection to U
A1, A2
Coupling terminal L1/+
L1/+
Coupling terminal L2/–
L2/–
No function
SS8103
Alarm resetting
ST6101
Connection procedure
1. Connect terminals E and KE to earth (PE).
2. Connect A and B to the BMS bus.
3. Connect terminal S to the shield of the bus line
(only at the end of the line).
4. Connect terminal L1/+ to L1/+ of the IT system
(with one 1 A fuse each).
5. Connect terminal L2/– to L2/– of the IT system
(with one 1 A fuse each).
6. Connect terminal A1/A2 to the supply voltage U
s
(with one 6 A fuse each).
7. Connect the alarm outputs 11/12/14, 21/22/24 and
31/32/34.
isoPV1685RTU_D00007_04_Q_DEEN / 02.2024
ISOMETER® isoPV1685RTU-425
Connections
= DC 24 V
s
s
5
