the device, except under supervision.
The device is intended to be used by
do-it-yourselfers. It was not designed for
commercial use. The warranty is void in the
case of commercial use. The manufacturer is
not liable for damage caused by improper
use or incorrect operation.
General description
An illustration of the most impor-
tant functional components can
be found on the fold-out pages.
Scope of delivery
First, unpack the device and check for com-
pleteness.
Dispose of the packaging material properly.
•
Cordless Planer
•
Suction adapter
•
Spanner
•
Allen key
•
Storage case
•
Operating instructions
The spanner and the Allen key are
stowed in the tool holder (13) in the
device. See the detailed illustration
on the fold-out page.
Battery and charger are
not included.
Observe the safety informati-
on and notes on charging and
proper use as shown in the instructi-
on manual for your battery and
charger from the Parkside
X 20 V Team series. A detailed de-
scription of the charging process and
further information can be found in
the separate operating instructions.
20
Description of functions
The cordless planer has a rotating planer
shaft, which is equipped with two blades.
The cordless planer can be used to plane
boards and beams.
The cordless planer is also suitable for
chamfering edges and creating rebates.
Please refer to the descriptions below for
information on how the operating elements
work.
Overview
1
Controller, cutting depth adjustment
2
Ejection chute
3
Safety switch
4
On/Off switch
5
Rechargeable battery
6
Release button
7
Planer sole
8
Suction adapter, left/right
9
Mounting screws
10 Allen key
11 Spanner
12 Device housing
13 Tool holder
14 Case
15
V-groove
16
Blade holder, planer blade
16.1 Back of blade holder
16.2 Front of blade holder
17
Hexagon bolt, blade fi xing
18
Screw,
blade height adjustment
19
Planer blade
20
Retractable planer blade guard
21
Planer shaft
22
Stop guard
optionally available:
23
Rip fence
24
Retaining screw
