Product contents and device overview

12
11
16

Description of accessories

• Turbo nozzle (10): The turbo nozzle has rotating cleaning brushes and is suitable
both for carpets and smooth fl oors.
• Floor nozzle (13): The fl oor nozzle is suitable both for carpets and smooth fl oors. The
fl at construction makes it possible to clean hard-to-reach areas like under the sofa,
under radiators etc.
• Tile nozzle (14): The tile nozzle is suitable for cleaning all nooks and crannies you
can't reach with other nozzles (e.g. between cushions). It has a fold-out brush adapt-
er for cleaning sensitive objects like keyboards.
• Brush nozzle (15): The brush nozzle is suitable for cleaning all uneven objects, furni-
ture, lamps, profi le strips and baseboards, window sills etc.
• Suction hose (16): You can use the suction hose to clean hard-to-reach areas.
09641_de-en-fr-nl_V2.indb 17 09641_de-en-fr-nl_V2.indb 17
17
1 Handle bar
2 Upper cord winder
1
3 Bracket for tile nozzle
2
4 Lower cord winder
5 Handle for use as a handheld vacuum
3 cleaner
6 On/Off switch
7 Motor unit
8 Two-piece dust fi lter in the dust bin
4
(fi ne fi lter and fabric fi lter)
5
9 Dust bin
10 Cleaning head turbo nozzle
6
11 Release button for removing the dust
7
bin
12 Latch for the handle bar
13 Floor nozzle
8
14 Tile nozzle
9 15 Brush nozzle
16 Suction hose
10
13
14
15
EN
