ISOMETER® isoNAV685-D
Werkseinstellungen
Ansprechwerte
Ansprechwert R (Alarm 1) .....................................................................5 kΩ
an
Ansprechwert DC-Verlagerungsspannung (Alarm 2) ............................. 150 V
Anlaufverzögerung T ............................................................................0 s
Anlauf
Schnittstellen
IP-Adresse ...................................................................... manuell 192.168.0.5
Netzmaske ............................................................................... 255.255.255.0
BCOM-Adresse .............................................................................. system-1-0
Digitale Eingänge
Arbeitsweise ..............................................................................X1.I1 & X1.I3:
........................................................................................................high-aktiv
Funktionen...................................................................................X1.I1: Reset;
.................................................................................X1.I3: Gerät deaktivieren
Digitale Ausgänge
Funktionen...................................................................X1.Q1: Isolationsfehler
..........................................................................+ DC-Verlagerungsspannung
Schaltglieder
Arbeitsweise ........................................................................ Ruhestrom (N/C)
Kontakt 11-12-14 ..................................................... Funktion 1: Iso. Alarm 1
Kontakt 21-22-24 ................................................Funktion 1: Isolationsfehler
..........................................................................+ DC-Verlagerungsspannung
Sonstiges
Netzform ..................................................................................................3 AC
Sprache .............................................................................................. Deutsch
Ankoppelüberwachung .............................................................................. ein
Fehlerspeicher............................................................................................ ein
Profil ......................................................................................Leistungskreise
8 isoNAV685-D_D00215_03_Q_DEEN / 03.2024
Factory settings
Response values
Response value R (Alarm 1) ...................................................................5 kΩ
an
Response value DC residual voltage (Alarm 2) ....................................... 150 V
Start-up delay T ....................................................................................0 s
Anlauf
Interfaces
IP-Adresse ....................................................................... manual 192.168.0.5
Network mask .......................................................................... 255.255.255.0
BCOMAddress ................................................................................ system-1-0
Digital Inputs
Mode ..........................................................................................X1.I1 & X1.I3:
.......................................................................................................active high
Functions .....................................................................................X1.I1: Reset;
...................................................................................X1.I3: Deactivate device
Digital Outputs
Functions .....................................................................X1.Q1: Insulation fault
..............................................................................................+ DC offset fault
Switching elements
Operating principle .....................................................................NC operation
Contact 11-12-14 ............................................ Function 1: Insulation Alarm 1
Contact 21-22-24 ............................................. Function 1: Insulation fault +
..................................................................................................DC offset fault
Other
Power supply system ...............................................................................3 AC
Language ............................................................................................German
Coupling monitoring ...................................................................................on
Fault memory .............................................................................................on
Profile .......................................................................................Power circuits
