! Sachschaden durch unsachgemäße
orsiCht
Installation! Die Anlage kann Schaden nehmen,
wenn Sie in einem leitend verbundenen System mehr
als ein Isolationsüberwachungsgerät anschließen.
Sind mehrere Geräte angeschlossen, funktioniert das
Gerät nicht und meldet keine Isolationsfehler.
Schließen Sie in jedem leitend verbundenen System
nur ein Isolations über wachungs gerät an.
I
V
! Trennung vom IT-System! Bei Isolations-
orsiCht
und Spannungsprüfungen an der Anlage muss das
Isolationsüberwachungsgerät für die Dauer der
Prüfung vom IT-System getrennt sein. Andern falls
kann das Gerät Schaden nehmen.
Maße
108
93
Maßangabe in mm
Montage
Montage auf Hutschiene / DIN rail mounting
2.
1.
3.
I
C
! Damage to property due to incorrect
aution
installation! There should only be one insulation
monitoring device per conductively connected in-
stallation. Damage to the installation may result if
several insulation monitoring devices are connect-
ed. In addition, the device will not function and
will not report an insulation fault if more than one
insulation monitoring device is connected.
I
C
! Disconnect from the IT system! The
aution
insulation monitoring device must be disconnect-
ed from the IT system before insulation or voltage
tests at the installation and must remain so for the
duration of the test. Otherwise the device may be
damaged.
Dimensions
110
0 mm
Dimensions in mm
Mounting
Schraubbefestigung /Screw mounting
isoNAV685-D_D00215_03_Q_DEEN / 03.2024
ISOMETER® isoNAV685-D
20 mm
20 mm
72
Ø M4
100
54
0 mm
