ELECTRIC CONNECTION
explosion, compliance is required with the appropriately valid national regulations and
installation regulations!
In the case of repair work or changes to explosion-proof apparatus, compliance is
required with the national regulations!
In the case of repair work and maintenance, GOK-original spare parts may only be used.
Changeover regulator of the
two-cylinder system
Signal transmitter for remote display
2-part (ring and cap)
T-piece with connection cable
between pressure and reed sensor
Connection cable transmitter for
remote display from pressure
sensor and reed sensor
Observe the installation conditions of EN1648-1 or EN1648-2 (Installation in caravans
and motor caravans) and EN ISO 10133 (Installation in small water vehicles).
• In order to conduct the connection cable
should be made to the interior. This cable bushing (e. g. with interior rubber grommet)
must be at least 50cm above the floor of the gas locker. Guide the connection cable with 3-
pin socket through this opening into the gas bottle locker.
Connection : between the 3-pin
connector and the 3-pin socket
• Always connect the wire colour of the connection cable (from pressure and reed sensor) of
the transmitter for remote display
• Guide connection cable
• The connection cable
not be extended by intermediate pieces. A length of less than 250mm (EN 1648-1) to the
interior space penetration is recommended.
• The opening to the interior space must then be sealed gastight (e.g. with bodywork
sealant).
• If cables are laid through the gas locker, they must be protected against mechanical
damage. Laying within a continuous cable duct or a conduit fulfils this requirement.
Artikel-Nr. 71 392 50 b
In the case of systems in connection with areas where there is a risk of
out of the gas bottle locker.
in the gas locker may not have any connection points and may
Information and control unit (control panel)
Cover frame
Connection cable for connection
Connection cable for connection to the
12V - power supply of the leisure vehicle
Cover socket
Connection between the 3-pin connector
and the 3-pin socket , Extension possible
(see LIST OF ACCESSORIES)
out of the gas locker, an appropriate opening
with the same connection cable
Caramatic BasicControl
wire colour!
