ASSEMBLY INFORMATION AND CONTROL UNIT (CONTROL PANEL)
Before assembly, check that the product for transport damage and is complete.
1. Remove the product from the box and remove the cover frame carefullyA surface-
mounted socket is not included in the delivery.
2. Wherever possible, designate the installation location for the control panel in a clearly
visible and accessible location and on a flat and smooth surface. To do so, make a
a. 55mm cutout. Avoid supporting structures in the wall for safety reasons.
3. Guide the connection cable
supply of the leisure vehicle) into the cut-out and lay them towards the battery
direction of the gas bottle locker
4. Mark four holes for the screws through the front panel.
5. Install the control panel. To do this, fit the front panel
with cover socket straight into the cutout and attach
to the wall with 4 screws.
6. Then attach the cover frame onto the control panel.
Installation of the signal transmitter
Only in combination with the two-cylinder system
Caramatic BasicTwo / Caramatic SafeDrive PLUS.
Observe the assembly and operating manuals.
• Fit the T-piece
changeover regulator
• Align "Operation" on the ring of the signal
transmitter above "operation" on the
changeover regulator
so that it is straight.
Artikel-Nr. 71 392 50 b
(with 3-pin plug) and connection cable
with connection G 3/8 lh nut to connection M G 3/8 lh M at the
, tightening torque 15 Nm.
, hold, then mount
.
• Align the cap with nib of the signal
transmitter
changeover regulator
mount so that it is straight.
Caramatic BasicControl
(12 V power -
over the nib of the
, hold, then
or in the
